Neo-Flex® Mobile MediaCenter VHD

Ergotron

About the Product

This flat panel cart stretches your investment by serving a variety of projection needs. Features include portrait-to-landscape rotation, 20″ (51 cm) effortless height adjustment and 20° independent display tilt. Handles displays weighing 50–90 lbs (23–41 kg).

Get optimal positioning for both seated and standing audiences, in any application, in any part of your facility.

Product Benefits
– Move digital content to where you need it
– Rotate your display to portrait or landscape orientation—no need to reinstall display
– Optional camera shelf accessory converts any space into a video conference center
– Easily roll cart through standard-size doorways and over thresholds
– Narrow footprint allows presenter to move closer to the display; easily tucks into corners or nests with other carts for space-saving storage
– Constant Force™ technology enables smooth, effortless portrait-to-landscape rotation, tilt and height adjustment. Adjusts with just a touch—no knobs or levers
– Modular cable management channels conceal and organize cables
– Maximize your technology investment by sharing a large display over multiple rooms
– Second-generation design and 47 separate quality tests ensure reliability and optimum performance
– Speedy assembly and installation

Tech Specifications
SCREEN 37” – 75”
CAPACITY 5090 lbs 22.740.8 kg
LIFT 20” 50.8 cm
TILT 20°
ROTATION 90°
VESA MIS-D/F*
WARRANTY 3 years

Neo-Flex Mobile MediaCenter VHD Very Heavy Duty (black)
– Includes cart, display and pan assembly, lower main shelf, 4-inch (100 mm) casters (two locking), rear cable shelf, cable channel kit
– Complies with UL Tip Standards 1667 and 1678
– Rugged plastic-composite shelf conveniently attaches to cart at any height
– Modular cable channel system is adaptable for various wiring configurations
– Add the MMC Camera Shelf Kit to place adjustable camera shelf above the display (ordered separately)
– CPUs attach safely to rear of cart with Universal CPU Holder accessory (ordered separately). Compatible with CPU sizes from 12″ H x 3″ D to 18″ H x 8.5″ D (300 x 80 mm to 460 x 220 mm)
– ‡ Listed screen size represents typical size of display used with this cart. However, weight of display and its VESA hole pattern—not its screen size—are the determining factors for compatibility
– † Weight Capacity: main shelf = 30 lbs (13.6 kg); cable shelf = 5 lbs (2.2 kg); if MMC Video-Conferencing Kit is added, display weight capacity is diminished by 5 lbs (2.3 kg); if 800 mm Accessory Kit is added, display weight capacity is diminished by 5 lbs (2.3 kg)
– * Mounting Hole Patterns: Horizontal measurement = 200 mm, 300 mm, 400 mm, 500 mm or 600 mm. Vertical measurement = 200 mm or 225 mm to 400 mm. Also accommodates MIS-D 100 x 100 mm hole pattern. With optional 800 mm Accessory Kit (97-489, ordered separately), horizontal measurement can be expanded to 800 mm or 660 mm
– Note: Portrait orientation is not recommended for some plasma displays. Contact display manufacturer if you have questions regarding your plasma’s portrait-mode capability (this is not an issue with LCD technology)
– Shipping Dimensions: 66″L x 20″H x 14″D (1680 x 503 x 335 mm)
– Shipping Weight: 101 lbs (46 kg)
– Warranty: 3 years
